Volvo EC 220

We have all the parts for the machinery:ROCK BUCKET/SKELETON BUCKET /LOOSENING BUCKET/CLEANING BUCKET TILT BUCKET/DITCH BUCKET/BUCKET CLAMP/CLAMSHELL BUCKET/ROTARY SCREEN/CRUSHER BUCKET/RUSHER BUCKET CRUSHING AND SCREENING BUCKET/RAKE/RIPPER/THUMB CLIP/COMPACTION WHEEL Business hours:24 hours, holidays and Sundays Contact: Jason Whatsapp: +86 13675656717 Mobile:+86 13675656717 Wechat:13675656717 Packaging Details 1. Flat frame is more suitable for large construction equipment without disassembly. 2. Containers are the cheapest and fastest. 3. Bulk carriers are more suitable for large construction equipment. 4. Ro-ro shipment is fast and suitable for all kinds of machines. You can choose any mode of transportation according to your needs.

Parameter configuration of Volvo EC220 excavator Specification Power Traditional Power Joint venture/import by manufacturers Bucket backhoe Tonnage (tons)22 The working weight of the entire machine (kg) is 20,900-24,400 Bucket capacity (m³) : 0.48-1.44 Origin: South Korea Performance Rotational speed (rpm)12.1 The rotary torque (Nm) is 76.7 Walking speed (km/h) : 3.5/5.7 Bucket digging force (kN)127 The digging force of the boom (kN) is 93 Maximum traction force (kN)183 Power system Engine model: Volov D6H Rated power (kw/rpm) : 123/1800 Maximum torque (N.m) : 849/1350 Displacement (L)5.7 Number of cylinders (6 Cylinder diameter × stroke (mm)98×126 Hydraulic system Pilot oil circuit (MPa)3.9 Working hydraulic circuit (Mpa)34.3/36.2 Walking hydraulic circuit (Mpa)34.3 Rotary hydraulic circuit (Mpa)27.9 Oil capacity Fuel tank (L)375 Hydraulic oil tank (L)140 Hydraulic system (L)295 Coolant (L)32 Main body size The total length of transportation (mm) is 9795 The total transportation width (mm) is 2700 The total height of the cab (mm) is 2930 The width of the vehicle (mm) is 2700 The total length of the tracks (mm) is 4160 Track plate width (mm) : 600 The total width of the tracks (mm) is 2200 The ground clearance of the counterweight (mm) is 1025 Minimum ground clearance (mm) : 460 Rear end turning radius (mm) : 2750 Number of idler wheels (single side) (units)2 Number of track plates (single side) (pieces)46 Number of supporting wheels (single side) (units)7 Scope of work Maximum excavation radius (mm) : 9970 Maximum excavation depth (mm) : 6760 Maximum excavation height (mm) : 9470 Maximum unloading height (mm) : 6620
