Sany STC 800

Fly Jib ,Hook ,Counter Weight, ETC. We have all the parts for the machinery:ROCK BUCKET/SKELETON BUCKET /LOOSENING BUCKET/CLEANING BUCKET TILT BUCKET/DITCH BUCKET/BUCKET CLAMP/CLAMSHELL BUCKET/ROTARY SCREEN/CRUSHER BUCKET/RUSHER BUCKET CRUSHING AND SCREENING BUCKET/RAKE/RIPPER/THUMB CLIP/COMPACTION WHEEL Business hours:24 hours, holidays and Sundays Contact: Jason Whatsapp: +86 13675656717 Mobile:+86 13675656717 Wechat:13675656717 Packaging Details 1. Flat frame is more suitable for large construction equipment without disassembly. 2. Containers are the cheapest and fastest. 3. Bulk carriers are more suitable for large construction equipment. 4. Ro-ro shipment is fast and suitable for all kinds of machines. You can choose any mode of transportation according to your needs.

Parameter configuration of Sany STC800 crane Lifting capacity Maximum rated lifting capacity (t)80 Maximum rated lifting moment (KN.m)3557 Maximum lifting height - fully extended boom (m)87 Maximum lifting capacity (tons) : 45-90 tons Operation speed parameter The maximum lifting speed of the main hoist (m/min) is 135 The full extension time of the boom (s) is 460 Rotational speed (rpm) : 1.5 Engine The chassis engine model is Weichai WP10H Rated power (kw/rpm) : 276/1900 Driving parameters Maximum driving speed (km/h) : 90 Minimum turning radius (m) : 12 Maximum climbing gradient (%)49 Approach Angle/departure Angle (°)18/13 Overall machine specification The total length of the entire machine is 15,290 mm The full width of the entire machine (mm) is 2800 The overall height of the machine (mm) is 3880 Working weight (t) : 50 Total counterweight (t)26 Outrigger span Longitudinal × transverse (m)6.53*8.0
